- General Information
- Manufacturer
- Axis Communications
- Manufacturer Website Address
- http://www.axis.com/uk
- Brand Name
- AXIS
- Product Type
- PoE Injector
AXIS 90 W Midspan AC/DC is perfect for installations where mains power is not an option. With a power input of either 24 V AC or 20-26.4 V DC, it can deliver up to IEEE 802.3bt (90 W) to your network device. AXIS 90 W Midspan AC/DC is plug-and-play and compatible with all Axis PoE devices which require up to 90 W power.
24 V AC can be needed in harsh environments where new cabling or installations are not an option and you need to retrofit box, dome or PTZ cameras.
20-26.4 V DC can be used where battery back-up is needed or for solar-powered installations. Or when the network device is built in another equipment and is powered directly from it, for example, in an ATM.
- Power Description
- Input Voltage
- 26.4 V DC
- 20 V DC
- Maximum Output Voltage
- 56 V DC
- Maximum Output Power
- 90 W
- Interfaces/Ports
- Input Ports
- 1 x Gigabit Ethernet
- Output Ports
- 1 x Gigabit PoE
- Physical Characteristics
- Product Color
- Black
- Form Factor
- Wall/Shelf/DIN Rail Mountable
- Height
- 43.2 mm
- Width
- 78.7 mm
- Depth
- 188 mm
- Weight (Approximate)
- 500 g
- Miscellaneous
- Compatibility
- P8815-2 3D People Counter
- D4100-E Network Strobe Siren
Fixed Box Cameras:
- M1055-L
- M1075-L
- M1135 Mk II
- M1135-E Mk II
- M1137 Mk II
- M1137-E Mk II
- P1375
- P1375-E
- P1377
- P1377-LE
- P1378
- P1378-LE
- Q1615 Mk III
- Q1615-LE Mk III
- Q1656
- Q1656-B
- Q1656-BE
- Q1656-BLE
- Q1656-DLE
- Q1656-LE
- M2035-LE
- M2036-LE
- P1455-LE
- P1465-LE
- P1467-LE
- P1468-LE
- Q1700-LE
- Q1715
- Q1785-LE
- Q1786-LE
- Q1798-LE
- M3057-PLVE Mk II
- M3058-PLVE
- M3067-P
- M3068-P
- M3077-PLVE
- M3085-V
- M3086-V
- M3088-V
- M3115-LVE
- M3116-LVE
- M3215-LVE
- M3216-LVE
- M3905-R
- M4216-LV
- M4216-V
- M4308-PLE
- P3255-LVE
- P3265-LV
- P3265-LVE
- P3265-V
- P3267-LV
- P3267-LVE
- P3268-LV
- P3268-LVE
- P3719-PLE
- P3727-PLE
- P3904-R Mk II
- P3905-R Mk II
- P3925-LRE
- P3925-R
- P3935-LR
- P4705-PLVE
- P4707-PLVE
- P9106-V
- Q3536-LVE
- Q3538-LVE
- Q3538-SLVE
- Q9216-SLV
- F34
- F41
- F44
- F9104-B
- F9111
- F9114
- F9114-B
- FA51
- FA51-B
- P1245
- P1265
- P1275
- P1280-E
- P1290-E
- A9161
- A9188-VE
- C1310-E
- C1410
- C1610-VE
- F41
- M3905-R
- P3904-R Mk II
- P3905-R Mk II
- P3925-LRE
- P3925-R
- P3935-LR
- M5000
- M5000-G
- M5074
- M5075
- M5075-G
- M5525-E
- P5676-LE
- Q6010-E
- Q6074
- Q6074-E
- Q6075
- Q6075-E
- Q6078-E
- Q6100-E
- Q6135-LE
- Q6225-LE
- Q6315-LE
- Q6318-LE
- M3057-PLVE Mk II
- M3058-PLVE
- M3067-P
- M3068-P
- M3077-PLVE
- M4308-PLE
- P3719-PLE
- P3727-PLE
- P4705-PLVE
- P4707-PLVE
- P9106-V
- Q9216-SLV
- P1280-E
- P1290-E
- Q1941-E
- Q1941-E
- Q1942-E
- Q1942-E
- Q1951-E
- Q1952-E
- Q1961-TE
- M7104
- P7304
