- General Information
- Manufacturer
- Axis Communications
- Manufacturer Website Address
- http://www.axis.com/uk
- Brand Name
- AXIS
- Product Series
- P14
- Product Type
- Network Camera
This robust, impact-resistant camera delivers excellent image quality in 5 MP under any light conditions. It comes with a 3-8.5 mm wide-angle lens. Zipstream with support for AV1, H.264, and H.265 significantly lowers bandwidth and storage costs. Built on ARTPEC-9, it offers accelerated performance to run impressive analytics applications on the edge and comes with AXIS Object Analytics and AXIS Image Health Analytics preinstalled. This outdoor-ready camera can handle extreme temperatures. It's easy to install, maintain, and operate. What's more, Axis Edge Vault, our hardwarebased cybersecurity platform, safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operation.
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 50 m
- Night Vision Type
- Infrared
- Camera Iris
- P-iris
- AI-powered
- Yes
- Infrared (IR) Cut-off Filter
- Yes
- Languages Support
- English
- German
- French
- Spanish
- Italian
- Korean
- Japanese
- Polish
- Russian
- Simplified Chinese
- Vietnamese
- Finnish
- Czech
- Turkish
- Thai
- Traditional Chinese
- Portuguese
- Dutch
- Swedish
- Wide Dynamic Range Detail
- 120 dB
- Display & Graphics
- Image Sensor Type
- RGB CMOS
- Image Sensor Size
- 1/2.8"
- Colour Supported
- Colour
- Field of View
- Horizontal field of view 106°-35°
- Vertical field of view 77°-26°
- Effective Camera Resolution
- 5 Megapixel
- Video
- Video Formats
- AVI
- H.264
- H.265
- Motion JPEG
- Zipstream
- H.264B (MPEG-4 Part 10/AVC)
- H.264H (MPEG-4 Part 10/AVC)
- H.264M (MPEG-4 Part 10/AVC)
- Maximum Video Resolution
- 2592 x 1944
- Maximum Frame Rate
- 30 fps
- Audio
- Audio Support
- Yes
- Lens
- Lens Type
- Varifocal
- Minimum Focal Length
- 3 mm
- Maximum Focal Length
- 8.50 mm
- Lens Included
- Yes
- Minimum Aperture
- f/2.58
- Maximum Aperture
- f/1.36
- Optical Zoom
- 2.8x
- Exposure
- Shortest Shutter Speed
- 1/30500 Second
- Longest Shutter Speed
- 2 Second
- PTZ Modes
- Digital PTZ
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Gigabit Ethernet
- Protocols
- IPv4
- IPv6 USGv6
- ICMPv4/ICMPv6
- HTTP
- HTTPS
- HTTP/2
- TLS
- TCP
- UDP
- IGMPv1/v2/v3
- ICMP
- DHCPv4/v6
- ARP
- SSH
- DiffServ (QoS)
- FTP
- SFTP
- CIFS/SMB
- SMTP
- UPnP
- SNMPv1/v2c/v3 (MIB2)
- DNS/DNSv6
- DDNS
- NTP
- NTS
- RTCP
- RTSP
- RTP
- LLDP
- MQTT v3.1.1
- Syslog
- ZeroConf
- IEEE 802.1AR
- IEEE 802.1X (EAP-TLS)
- ONVIF
- mDNS (Bonjour)
- SRTP/RTSPS
- MQTT
- CDP
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Internal Memory
- 2 GB
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Maximum Power Consumption
- 12.95 W
- Input Voltage
- 28 V DC
- 10 V DC
- Power Source Type
- PoE
- DC
- Physical Characteristics
- Form Factor
- Bullet
- Durability
- Impact Resistant
- Vibration Resistant
- Color Family
- White
- Product Color
- White
- Product Material
- Aluminium
- Polycarbonate
- Weight (Approximate)
- 1.37 kg
- Environmental Conditions
- Minimum Operating Temperature
- -40°C
- Maximum Operating Temperature
- 60°C
- Minimum Storage Temperature
- -40°C
- Maximum Storage Temperature
- 65°C
- Minimum Operating Humidity (Condensing)
- 10%
- Maximum Operating Humidity (Condensing)
- 100%
- Minimum Storage Humidity (Non-condensing)
- 5%
- Maximum Storage Humidity (Non-condensing)
- 95%
- Miscellaneous
- Features
- Electronic Image Stabilization
- SD Card Local Storage
- Built-in Cybersecurity
- AI Analytics
- HTTPS Encryption
- Password Protection
- Privacy Masking
- Vehicle Detection
- Human Detection
- Ingress Protection
- Motion Detection
- Indoor/Outdoor
- Indoor/Outdoor
- Package Contents
- P1487-LE Bullet Camera
- Weathershield
- Installation guide
- Terminal block connector
- Connector guard
- Cable gaskets
- Owner authentication key
- Impact Protection Rating
- IK10
- Ingress Protection Rating
- IP66
- IP67
- Country of Origin
- Poland
- TAA Compliant
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
