- General Information
- Manufacturer
- Bixolon America, Inc
- Manufacturer Website Address
- http://www.bixolon.com
- Brand Name
- Bixolon
- Product Type
- Direct Thermal Printer
Productive Performance
- Fast linerless printing speed up to 6 ips (152 mm/sec)
- Dual-mode Bluetooth (V4.2 Classic and LE) or Dual-band WLAN (5GHz and 2.4 GHz) connectivity
- Twin function™ and free advanced-level label editing software
- SoftAP & Smart Connection™- Easy Wi-Fi setup
- XPM™ & XCM™- Web-based printer management software and connection app
User-Centred Design
- 2 long lasting Platen Rollers ensuring reliability : When the lower platen roller is worn, it can be switched with the upper roller
- LED or LCD menu choices - Special paper path design, guillotine cutting system and Anti-Curl support
- Media Support preventing the cut media falling to the desk, counter space or floor
- Full-width Auto Cutter with Taken sensor™
- Two colour choices of either Ivory or Dark Gray design to suit point of use
Benefit of Using Linerless Labels
- Eliminating waste management process or landfill costs of the liner-backing
- Reducing freight expenses of label rolls
- CO2 emissions decrease with no liner incineration
- Up to 40% more label length available on a linerless paper per roll compared to linered media
- Technical Information
- Recommended Use
- Label Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 127 mm/s
- Maximum Print Resolution (dpi)
- 300
- Maximum Print Length
- 1000 mm
- Maximum Print Width
- 105.70 mm (4.16")
- Barcode Symbology Supported
- PDF417
- QR Code
- Maxi Code
- Data Matrix
- Code 49
- Codablock
- IMB
- UPC-E
- UPC-A
- UPC/EAN
- Standard 2 of 5
- GS1 DataBar (RSS-14)
- POSTNET
- Plessey
- MSI
- LOGMARS
- Interleaved 2 of 5
- Industrial 2 of 5
- EAN-8
- EAN-13
- Code 128
- Code 93
- 2D
- Codabar
- Code 11
- Code 39
- AZTEC
- TLC 39
- Micro PDF-417
- Application/Usage
- Retail
- Manufacturing
- Logistic
- Hospitality
- Desktop
- Features
- Twin Function
- Print Technology
- Direct Thermal
- Memory
- Standard Memory
- 64 MB
- Flash Memory
- 128 MB
- Interfaces/Ports
- Serial Port
- Yes
- USB Host
- Yes
- USB
- Yes
- USB Standard
- USB 2.0
- Network & Communication
- Ethernet
- Yes
- Ethernet Technology
- Ethernet
- Display & Graphics
- Display Screen
- Yes
- Screen Size
- 10.2 cm (4")
- Display Screen Type
- LCD
- Media Types & Handling
- Media Type
- Label
- Linerless
- Black Mark
- Gap
- Media Sensor
- Gap Sensor
- Black Mark Sensor
- Adjustable Media Sensor
- Head Open Sensor
- Label Taken Sensor
- Media Thickness
- 200 µm
- Maximum Roll Diameter
- 127 mm
- Maximum Label Width
- 114 mm
- Fonts & Emulation
- Language Emulation
- SLCS
- BPL-Z
- ZPL II
- BPL-E
- EPL
- Power Description
- Power Source
- Power Adapter
- AC Supply
- Frequency
- 60 Hz
- 50 Hz
- Environmental Conditions
- Operating Temperature
- 0°C - 40°C
- Operating Relative Humidity
- 10% - 80%
- Storage Temperature
- -20°C - 60°C
- Storage Relative Humidity
- 10% - 90%
- Physical Characteristics
- Height
- 173 mm
- Width
- 186 mm
- Depth
- 287.7 mm
- Weight (Approximate)
- 2.80 kg
- Miscellaneous
- Energy Star
- Yes
