Cisco Catalyst 9300 C9300X-48HX 48 Ports Manageable Ethernet Switch - 10 Gigabit Ethernet, 5 Gigabit Ethernet - 10GBase-T

  • Part: 1715234
  • Model: C9300X-48HX-M
£13,388.00

Availability

Out of Stock

Built to reimage connection, reinforce securityand redefine experience

Cisco®Catalyst®9300 Series switches are Cisco's lead stackable enterpriseaccessswitching platformand as part of the Catalyst 9000 family, are build to transform your network to handle a hybrid world where the workplace is anywhere, endpoints could be anything, and applications are hosted all over the place.

The Catalyst 9300 Series, including the new Catalyst 9300X models, continues to shape the future with continued innovation that helps you reimagine connections, reinforce security and redefine the experience for your hybrid workforce big and small.

The many industry'sfirst include:

  • Up to 1TB of stacking bandwidth: With Stackwise-1T, Catalyst 9300switches are the industry's highest-density stacking bandwidth solution with the most flexible uplink architecture
  • Flexible and dense uplink offeringswith 100G, 40G, 25G, Multigigabit, 10G, and 1G modular uplinks
  • Mixed Stacking with Backward Compatibility -Stack your Catalyst 9300X fiber switches with Catalyst 9300and Catalyst 9300X Multigigabit switches, bringingstackable high-speed fiber to the access
  • Highest Multigigabit Ports:With standalone and Stackwise-1T,Catalyst 9300X models enable 48 mGig ports in standalone and 448 mGig ports with an 8-member stack
  • Highest 90W UPOE®+ Density: Enable your OT/IT needs with up to 36 ports of 90W UPOE+ for standalone or 288 ports of 90W UPOE+ with a 8-member stack.
  • StackPower with Backward Compatibility: Enable power resiliency with higher power budgets in mixed Catalyst 9300and Catalyst 9300X stack.
  • 100G IPsec in hardware: With the new 2.0Sec UADP ASIC, the Catalyst 9300X comes with 100G line rate IPsecto enable various options for new edge connectivity
  • Secure Tunnel connectivity: With the new edge, the C9300X enables secureconnections to Secure Internet Gateway, Cloud Service Providers and Site to Site connectivity using IPsec tunnel with AES-256 Encryption and speeds up to 100G.
  • Enhanced Application Hosting: With 2x capacity and additional RAM, QAT, and 2 x 10G AppGig Ports, multiple Cisco Signed performance savvy applications can be hosted on Catalyst 9300X
  • ThousandEyes Enabled:End-to-end visualization of the path from campus/branch to clouds/DC with Cisco ThousandEyes Network and Application Synthetics (included with Cisco DNA Advantage licenses)
  • Investment Protection: Catalyst 9300X redundant fansandpower supplies, data stack and StackPower cables are backward compatible with the Catalyst 9300

The Foundation of Software-Defined access

Advanced persistent security threats. The exponential growth of Internet of Things (IoT) devices. Mobility everywhere. Cloud adoption. All of these require a network fabric that integrates advanced hardware and software innovations to automate, secure, and simplify customer networks. The goal of this network fabric is to enable customer revenue growth by accelerating the rollout of business services. The Cisco Digital Network Architecture (Cisco DNA) with Software-Defined Access (SD-Access) is the network fabric that powers business. It is an open and extensible, software-driven architecture that accelerates and simplifies your enterprise network operations. The programmable architecture frees your IT staff from timeconsuming, repetitive network configuration tasks so they can focus instead on innovation that positively transforms your business. SD-Access enables policy-based automation from edge to cloud with foundational capabilities. These include:

  • Simplified device deployment
  • General Information
    • Manufacturer
    • Cisco Systems, Inc
    • Manufacturer Website Address
    • http://www.cisco.com
    • Brand Name
    • Cisco
    • Product Line
    • Catalyst
    • Product Series
    • 9300
    • Product Type
    • Ethernet Switch
  • Warranty
    • Limited Warranty
    • Lifetime

  • Interfaces/Ports
    • Total Number of Network Ports
    • 48
    • Uplink Port
    • Yes
    • Modular
    • Yes
    • Stack Port
    • Yes
    • Network (RJ-45)
    • Yes
    • Port/Expansion Slot Details
    • 8 x 10 Gigabit Ethernet UPoE+
    • 1 x Uplink
    • 40 x 5 Gigabit Ethernet UPoE+
  • Media & Performance
    • Media Type Supported
    • Twisted Pair
    • Ethernet Technology
    • 10 Gigabit Ethernet
    • 5 Gigabit Ethernet
    • Network Technology
    • 10GBase-T
  • I/O Expansions
    • Number of Total Expansion Slots
    • 1
    • Expansion Slot Type
    • Uplink Module
  • Network & Communication
    • Layer Supported
    • 3
    • Networking Standards
    • IEEE 802.1br
    • IEEE 802.1ae
    • IEEE 802.1s
    • IEEE 802.1w
    • IEEE 802.1AVB
    • IEEE 802.3bt
    • IEEE 802.1x
    • IEEE 802.3ad
    • IEEE 802.3at
    • IEEE 802.3af
    • IEEE 802.3x
    • IEEE 802.1D
    • IEEE 802.1p
    • IEEE 802.1Q
    • IEEE 802.3u
    • IEEE 802.3
    • IEEE 802.3ab
    • IEEE 802.3z
    • IEEE 802.3bz
    • IEEE 802.3an
  • Management & Protocols
    • Manageable
    • Yes
  • Power Description
    • PoE (RJ-45) Port
    • Yes
    • PoE Budget
    • 90 W
    • Input Voltage
    • 120 V AC
    • 230 V AC
    • Frequency
    • 50 Hz
    • 60 Hz
    • Power Source
    • Power Supply
    • AC
    • Redundant Power Supply Supported
    • Yes
    • Number of Power Supplies Supported
    • 2
    • Number of Power Supplies Installed
    • 1
    • Power Consumption
    • 1100 W
  • Physical Characteristics
    • Color Family
    • Grey
    • Product Color
    • Grey
    • Form Factor
    • Rack-mountable
    • Height
    • 43.9 mm
    • Width
    • 444.5 mm
    • Depth
    • 446.3 mm
    • Weight (Approximate)
    • 6.44 kg
  • Miscellaneous
    • Package Contents
      • Catalyst C9300X-48HX Ethernet Switch
      • 1 x Power Supply
      • 3 x Field-Replaceable Fans
    • Application/Usage
    • Data Center
    • Branch Office
    • Business
    • Enterprise
    • IP Phone
    • Campus
    • Wireless Access Point
    • Certifications & Standards
      • UL 60950-1
      • CAN/CSA-C222.2 No. 60950-1
      • EN 60950-1
      • IEC 60950-1
      • AS/NZS 60950.1
      • IEEE 802.3
      • 47 CFR Part 15
      • EN 300 386 V1.6.1
      • EN 55032 Class A
      • CISPR 32 Class A
      • EN61000-3-2
      • EN61000-3-3
      • ICES-003 Class A
      • TCVN 7189 Class A
      • V-3 Class A
      • CISPR 35
      • EN 300 386
      • EN 55035
      • TCVN 7317
      • V-2/2015.04
      • V-3/2015.04
      • CNS13438
      • KN32
      • KN35
    • Environmentally Friendly
    • Yes
    • Environmental Certification
    • RoHS-5
    • WEEE
