- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco Meraki
- Product Series
- MS130
- Product Type
- Ethernet Switch
Cisco Meraki MS130 switches provide Layer 2 access switching, ideal for branch and campus deployments. The MS130 series features a variety of options designed to meet the diverse needs of branch and campus deployments.
With 10 different models, capable of providing up to 740W of power over a variety of port densities, including SFP+ capable uplinks, the MS130 line is fully ready to support future wireless infrastructure deployments across a variety of different environments.
- Technical Information
- Features
- DHCP Snooping
- Interfaces/Ports
- Total Number of Network Ports
- 8
- Uplink Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 8 x Gigabit Ethernet Netowrk
- 2 x Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- 1000Base-X
- Maximum Data Transfer Rate
- 128 MB/s
- I/O Expansions
- Total Number of Expansion Slots
- 2
- Expansion Slot Type
- SFP
- Number of SFP Slots
- 2
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.3bt
- Management & Protocols
- Manageable
- Yes
- Reliability
- MTBF
- 608122 Hour
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 120 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- AC
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Desktop
- Wall Mountable
- Height
- 44.4 mm
- Width
- 228.6 mm
- Depth
- 217.9 mm
- Weight (Approximate)
- 960 g
- Miscellaneous
- Application/Usage
- Campus
- Infrastructure
- Network
- Server
