- General Information
- Manufacturer
- Datalogic S.p.A
- Manufacturer Website Address
- http://www.datalogic.com
- Brand Name
- Datalogic
- Product Line
- PowerScan
- Product Series
- 9600
- Product Type
- Barcode Scanner Kit
ULTRA-RUGGED WITH NEW BALANCED ERGONOMICS
The PowerScan family of bar code readers are the ultimate industrial handheld scanners designed and constructed to withstand the toughest environmental conditions. The PowerScan 9600 imagers have an ultra-rugged design, an ergonomic shape with well-balanced weight to reduce operator stress during daily activities and an intuitive aiming system, allowing the highest first-pass reading rate while reducing unnatural wrist movement.
MOBILITY ENHANCES PRODUCTIVITY
The PowerScan 9600 cordless model further enhances the operator efficiency and safety with Datalogic's STAR Cordless System. Accurate power management allows long lasting battery life to always guarantee more than one shift of intensive scanning. The PowerScan 9600 scanner features Datalogic's Wireless Charging System. Based on inductive-charging technology, Datalogic's Wireless Charging System eliminates battery contacts and pins that often get dirty, bent, or broken over time - and this removes a key point of failure for devices used in industrial and retail functions.
MODULARITY WITH THE BEST FLEXIBILITY
The BC9600 base/charger has a modular design and is available with multiple interface plug-ins for standard and industrial communication, such as RS-232, USB, Standard Ethernet and Industrial Ethernet protocols
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Connectivity Technology
- Wireless
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
1D / Linear Codes:
- Auto discriminates all standard 1D codes including GS1 DataBar linear codes.
2D Codes:
- Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Codee; Dot code
Postal Codes:
- Australian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish Post
Stacked Codes:
- EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites
Digital Watermarking:
- Digimarc Barcodes (HP and DC models)
- Light Source
- LED
- Image Sensor Type
- Imager
- Scan Mode
- Trigger
- Scan Pattern
- Omni-directional
- Scanner Range
- Standard Range
- Scanning Distance
- 1.75 m
- Features
- Vibration
- 3GL
- Ergonomic Design
- Notification LED
- Display Screen
- Yes
- Field of View (Horizontal)
- 38°
- Field of View (Vertical)
- 24°
- Reading Angle (Skew)
- 52°
- Reading Angle (Pitch)
- 52°
- Reading Angle (Roll)
- 360°
- Maximum Ambient Light
- 100000 lux
- Drop Specification
- Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F
- Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F
- Minimum Print Contrast
- 15%
- Minimum Element Resolution (DataMatrix)
- 0.25 mm
- Image Sensor Resolution
- 1280 x 800
- Illumination Type
- LED
- Illumination Color
- White
- Air Electrostatic Discharge (+/-)
- 20kV
- Network & Communication
- Radio Frequency
- Yes
- Interfaces/Ports
- Host Interface
- USB
- Power Description
- Power Supply Included
- Yes
- Input Current
- 480 mA
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Capacity
- 3350 mAh
- Maximum Battery Recharge Time
- 3.20 Hour
- Environmental Conditions
- Operating Temperature
- -20°C to 50°C
- Storage Temperature
- -40°C to 70°C
- Humidity (Non-condensing)
- 0% to 95%
- Physical Characteristics
- Form Factor
- Handheld
- Rugged
- Yes
- Color Family
- Dual Colour
- Product Color
- Black
- Yellow
- Height
- 198.1 mm
- Width
- 78.7 mm
- Length
- 139.7 mm
- Miscellaneous
- Package Contents
- 1 x PowerScan PM9600 Barcode Scanner
- 1 x Cradle
- 1 x Cable
- 1 x Power Supply
- 1 x Power Cord
- Ingress Protection (IP) Rating
- IP65
- IP67
- Application/Usage
- Industrial
- Warehouse
- Manufacturing
- Logistics
- Retail
- Inventory
- Assembly Line
- Picking
- Component Tracking
- Sorting
- Environmentally Friendly
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
- China Restriction of Hazardous Substances (China RoHS)
