- General Information
- Manufacturer
- Eaton Corporation
- Manufacturer Website Address
- http://www.powerquality.eaton.com/UK/
- Brand Name
- Eaton
- Product Series
- 9PX
- Product Type
- Double Conversion Online UPS
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Plug/Connector Type
- Hardwired
- Receptacle Type
- IEC 60320 C19
- Receptacle Detail
- 1 x Hardwired
- 4 x IEC 60320 C19
- Phase
- Three Phase
- Efficiency Detail
- 98% (ECO Mode)
- Power Description
- Load Capacity (VA)
- 8 kVA
- Load Capacity (Watt)
- 7.20 kW
- Input Voltage
- 380 V AC
- 400 V AC
- 415 V AC
- 480 V AC
- Input Voltage Range
- 305 V AC - 480 V AC
- Output Voltage
- 200 V AC
- 208 V AC
- 220 V AC
- 230 V AC
- 240 V AC
- 250 V AC
- Input Frequency
- 70 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Output Power Factor
- 0.9
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- Network Card
- Dry Contact
- DB-9 RS-232
- Relay-MS Card
- SNMP
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- USB (HID Compliant) Port
- Yes
- Battery Information
- Number of Batteries
- 20
- Battery Characteristics
- Sealed
- Battery Chemistry
- Lead Acid
- Battery Size
- 12V
- Battery Capacity
- 9000 mAh
- Backup/Run Time (Full Load)
- 5 Minute
- Backup/Run Time (Half Load)
- 16 Minute
- Hot Swappable
- Yes
- Replaceable Battery
- Yes
- Physical Characteristics
- Height
- 260 mm
- Width
- 440 mm
- Depth
- 700 mm
- Rack Height
- 6U
- Form Factor
- Rack/Tower
- Weight (Approximate)
- 88 kg
- Miscellaneous
- Package Contents
- 9PX8KIRTNBP31 8kVA Rack/Tower UPS
- Power Module
- Extended Battery Module (EBM)
- Maintenance Bypass
- Network Management Card
- 2 x Brackets For 19' Mounting
- 2 x Rack-Mounting Kit
- USB Cable
- Serial Cable
- Battery Cable With Comms For Automatic Battery Cabinet Recognition
- 2 x Supports For Tower Mounting
- Link Plate
- Safety Instructions
- Quickstart Guide
- Country of Origin
- China
