HPE AP-535 802.11ax 2.97 Gbit/s Wireless Access Point

  • Part: 1614277
  • Model: JZ334A
£1,590.00

Availability

Out of Stock

Aruba Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing numbers of IoT and mobility requirements. With a maximum real-world aggregate data rate of 2.97 Gbps (HE80/HE20), the 530 Series deliver the speed and reliability needed for any enterprise.

INCREDIBLE EFFICIENCY

The 530 Series APs are also designed to optimize user experience by maximizing Wi-Fi efficiency and dramatically reducing airtime contention between clients.

Features include Orthogonal frequency-division multiple access (OFDMA), bi-directional multi-user MIMO and cellular optimization. With up to 4 spatial streams (4SS) and 160MHz channel bandwidth (VHT160), the 530 Series provides groundbreaking wireless capabilities for any enterprise.

Read the Multi-User 802.11ax white paper for further information.

Advantages of OFDMA

This capability allows Aruba's APs to handle multiple Wi-Fi 6 capable clients on each channel simultaneously, regardless of device or traffic type. Channel utilization is optimized by handling each transaction via smaller sub-carriers or resource units (RUs), which means that clients are sharing a channel and not competing for airtime and bandwidth.

Aruba Air Slice™ for Extended Application Assurance

Initially, APs in controller-less mode (Instant) can provide SLA -grade performance by allocating radio resources, such as time, frequency, and spatial streams, to specific traffic types. By combining Aruba's Policy Enforcement Firewall (PEF) and Layer 7 deep packet inspection (DPI) to identify user roles and applications, the APs will dynamically allocate the bandwidth needed. Non-Wi-Fi 6 clients can also benefit.

Air Slice™ for APs uses Aruba Central for management. Controller-based APs will be supported in a future software release.

Bi-directional Multi-user MIMO (MU-MIMO)

Similar to downlink MU-MIMO in Wi-Fi 5 (802.11ac Wave 2), the 530 Series can simultaneously connect clients use downlink - and now - uplink spatial streams. The added benefit is the ability to multiply the number of clients that can now send traffic, thus optimizing client-to-AP spatial stream diversity.

Wi-Fi 6 and MU-MIMO aware client optimization

Aruba's patented AI-powered ClientMatch technology eliminates sticky client issues by placing Wi-Fi 6 capable devices on the best available AP. Session metrics are used to steer mobile devices to the best AP based on available bandwidth, types of applications being used and traffic type - even as users roam.

Aruba Advanced Cellular Coexistence (ACC)

This feature uses built-in filtering to automatically minimize the impact of interference from cellular networks, distributed antenna systems (DAS), and commercial small cell or femtocell equipment.

Intelligent Power Monitoring (IPM)

Aruba APs continuously monitor and report hardware energy consumption. They can also be configured to enable or disable capabilities based on available PoE power - ideal when wired switches have exhausted their power budget.

  • General Information
    • Manufacturer
    • Hewlett Packard Enterprise
    • Manufacturer Website Address
    • http://www.hpe.com
    • Brand Name
    • HPE
    • Product Series
    • 530
    • Product Type
    • Wireless Access Point

  • Technical Information
    • Wireless LAN Standard
    • 802.11ax
    • Bluetooth Standard
    • Bluetooth 5
    • Frequency Band
    • 2.40 GHz
    • 5 GHz
    • Total Number of Antennas
    • 4
    • Number of Internal Antennas
    • 4
    • Wireless Transmission Speed
    • 2.97 Gbit/s
    • MIMO Technology
    • Yes
    • Beamforming Technology
    • Yes
    • Data Encryption
    • Yes
    • Encryption Standard
    • WPA
    • WPA2
    • WPA3
    • WPA2-MPSK
  • Interfaces/Ports
    • Ethernet Technology
    • 5 Gigabit Ethernet
    • Number of Network (RJ-45) Ports
    • 2
    • PoE PD Port
    • Yes
    • USB
    • Yes
    • Management Port
    • Yes
  • Power Description
    • Power Consumption
    • 26.40 W
  • Physical Characteristics
    • Form Factor
    • Ceiling Mountable
    • Surface Mount
    • Height
    • 53 mm
    • Width
    • 240 mm
    • Depth
    • 240 mm
    • Weight (Approximate)
    • 1.27 kg
