Artistic Immersion, Overwhelming Captivation | Seamless Large Screens with Extreme-Narrow Bezel
The ultra slim bezel, with its 1.74mm BtoB (Panel Bezel to Panel Bezel), drastically reduces bezel interference and delivers immersive and seamless content on assembled video wall screens.
Image Gap Reduction
The VM5J-H includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
Higher Viewing Angle
Large screens are usually positioned higher than human-eye level. Wide half luminance angle (40°) enables effective picture quality for video walls. The viewing angle of the VM5J-H is high enough to display vivid colors throughout the screen without any color distortion.
Wider Viewing Angle
LG IPS panel technology enables stable and smooth control of liquid crystals, and allows the screen to be viewed from virtually any angle. Therefore, the VM5J-H captivates the attention of more viewers with lifelike colors, regardless of their viewing position.
Easy Color Adjustment
Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
Simple White Balance Adjustment
In conventional video walls, white balance was adjustable only in "full-white" mode, but the VM5J-H allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.
High Performance and Great Scalability
Thanks to its built-in SoC and webOS smart signage platform, the VM5J-H can execute several tasks at once while providing smooth content playback without the need for a media player. As webOS supports HTML5 as a web-based platform and offers SDK (Software Development Kit), it is even easier for SIs to build and optimize their web apps.
- General Information
- Manufacturer
- LG Electronics
- Manufacturer Website Address
- https://solutions.lg.com/us
- Brand Name
- LG
- Product Type
- Digital Signage Display
- Technical Information
- Features
- Smart Energy Saving
- FailOver
- Conformal Coating (Power Board)
- Carrying Handle
- Control Manager
- Auto Set ID
- Group Manager
- Tile Mode Setting (15 × 15)
- SNMP Manageable
- HDMI (CEC)
- Gyroscopic Sensor
- Temperature Sensor
- Pro:Idiom
- Wake on LAN (WOL)
- External Input Rotation
- Ingress Protection (IP) Rating
- IP5X
- Panel Technology
- In-plane Switching (IPS) Technology
- Operation Hours
- 24 Hours/7 Days
- Content Synchronization
- RS-232C
- Embedded CMS
- Local Contents Scheduling
- Image Sticking Minimization (ISM) Method
- Yes
- Display & Graphics
- Viewable Screen Size
- 55"
- Multi-touch Screen
- No
- Display Resolution
- 1920 x 1080
- Response Time
- 8 ms
- Aspect Ratio
- 16:9
- Horizontal Viewing Angle
- 178°
- Vertical Viewing Angle
- 178°
- Orientation
- Landscape/Portrait
- Maximum LED Life
- 6.8 Year
- Audio
- Speakers
- No
- Video
- Standard Refresh Rate
- 60 Hz
- Native Contrast Ratio
- 1,000:1
- Colour Depth
- 10-bit
- Brightness
- 500 cd/m²
- Color Gamut
- 72% NTSC
- Network & Communication
- Wireless LAN
- No
- Bluetooth
- No
- Interfaces/Ports
- Network (RJ-45)
- No
- USB Type-C
- No
- Infrared Output
- No
- Software
- Operating System
- webOS 4.1
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 40°C
- Minimum Operating Humidity
- 10%
- Maximum Operating Humidity
- 80%
- Physical Characteristics
- Bezel Color
- Black
- VESA Mount Standard
- 600 x 400
- Weight (Approximate)
- 18.78 kg
- Miscellaneous
- Additional Information
- Surface Treatment (Hard Coating) : No
- Surface Treatment (Anti Glare) : No
- Anti-Reflective : No
- Picture-by-Picture (PBP) : No
- U.S. ePEAT (Environmental) : No
- Transparency : No
- Internal Memory : 8 GB (eMMC)
- Cisco Certified Compatibility : No
- Direct Sunlight : No
- Bezel Width (Off Bezel) : T: 1.75 mm, R: 0.74 mm, L: 1.75 mm, B: 0.74 mm
- External Speaker Out (3.5 mm) : No
- Power Loop Out : No
- HDMI Out : No
- Power Loop In : No
- RGB In : No
- Power In (DC From External PWR Box) : No
- Anti-Reflective Coating : No
- Heater : No
- Anti-Reflective Film : No
- Heat Dissipation : No
- Degree of Protection : No
- OPS Power Built-in : No
- OPS Compatible : No
- SuperSign Media Editor : No
- SuperSign Cloud : No
- Mobile CMS : No
- UL Certification : No
- ISTA6 (Packaging) : No
- IR In (3.5 mm) : Yes
- RS-232C In (D-sub 9-pin) : Yes (x1)
- Power Type : Built-in Power
- Local Key Operation: Yes
- DisplayPort In : Yes (x1) HDCP 2.2
- Displayport Out : Yes (x1), input : HDMI / DVI / DP
- RS-232C Out (D-sub 9-pin) : Yes (x1)
- Energy Star
- Yes
- Country of Assembly
- Mexico
- TAA Compliant
- No
- Compatible Software
- SuperSign CMS
