- General Information
- Manufacturer
- Netgear, Inc
- Manufacturer Website Address
- http://www.netgear.co.uk
- Brand Name
- Netgear
- Product Line
- Business
- Marketing Information
Scale Beyond Gigabit with Adaptive Multi-Speed Networking
Engineered for modern multi-speed enterprise networks, NETGEAR's 5-Speed Multi-Gigabit switches intelligently adapt from 100Mbps to 10Gbps per port, delivering exact bandwidth each device needs.
With the demands of hybrid work, cloud services, AI-enhanced productivity tools, and high-definition video conferencing, modern networks need to extend beyond the 1-Gigabit barrier. The 10-Gigabit/ Multi-Gigabit Easy Smart Managed series from NETGEAR delivers on these evolving requirements, providing reliable 10-Gigabit/Multi-Gigabit bandwidth at an affordable cost.
Each port automatically detects which speed is needed by the connected device and provides the optimal performance. Unlike standard 10-Gigabit switches that only provide 1-Gigabit connectivity to devices requiring less than 10-Gigabit, the XS512EM and XS724EM deliver the exact speed required with no downgrades. Additionally, these NETGEAR MultiGigabit switch ports support a range of existing cable types-Cat5e cables for speeds up to 5 Gbps and Cat6/Cat6A for full 10-Gigabit performance maximizing your current infrastructure investment while providing flexible upgrade paths.
Highlights | Hardware Highlights
- 5-speed Networking
- XS512EMv2: 10-port Multi-Gigabit + 2 dedicated SFP+
- XS724EMv2: 24-port Multi-Gigabit + 4 dedicated SFP+
- Dedicated Fiber Uplinks: Pure SFP+ ports for high-speed backbone connections
- Rackmount or Desktop
- Active fans for whisper-quiet operation
- 0°C to 50°C tested performance
Software Highlights
- VLAN support for traffic segmentation
- Quality of Service (QoS) for traffic prioritization
- Auto "denial-of-service" (DoS) prevention Link Aggregation to add redundancy and increase your network speed (Static LAC and LACP supported)
- Loop prevention and broadcast storm controls
- IGMP snooping v1, v2 and v3 support for multicast optimization
- Rate limiting for better bandwidth allocation
- Port mirroring for network monitoring
- Jumbo frame support
- Energy Efficient Ethernet (IEEE802.3az) support for maximum power savings
- Troubleshoot connection issues via cable test
Industry leading warranty
- Limited Lifetime 24/7 Technical Support
- Product Type
- Ethernet Switch
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Features
- Energy Efficient
- Auto Denial of Service (DoS) Prevention
- Broadcast Storm Control
- Strict Priority Queuing (SPQ)
- AI-powered
- Yes
- Interfaces/Ports
- Total Number of Network Ports
- 10
- Uplink Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 10 x 1/2.5/10 Gigabit Ethernet RJ-45 Network Port
- 2 x 10 Gigabit Ethernet SFP+ Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- 2.5 Gigabit Ethernet
- 5 Gigabit Ethernet
- 10 Gigabit Ethernet
- Network Technology
- 100/1000Base-T
- 2.5GBase-T
- 5GBase-T
- 10GBase-T
- 10GBase-X
- Maximum Data Transfer Rate
- 1.25 GB/s
- I/O Expansions
- Total Number of Expansion Slots
- 2
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 2
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.3az
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.3x
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3an
- IEEE 802.3bz
- IEEE 802.3ae
- IEEE 802.3z
- Management & Protocols
- Manageable
- Yes
- Switch Management Type
- Easy Smart Managed
- Reliability
- MTBF
- 420709 Hour
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- AC
- Power Consumption
- 60 W
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- Desktop
- Rack-mountable
- Height
- 43.2 mm
- Width
- 327.7 mm
- Depth
- 208.3 mm
- Weight (Approximate)
- 2.50 kg
- Miscellaneous
- Package Contents
- Business XS512EMv2 Ethernet Switch
- Power cord (localized to country of sale)
- Rackmount kit
- Documentation Flyer
- Application/Usage
- Network
- Enterprise
- Infrastructure
- Traffic
- Office
