Zebra FS40 Rugged Industrial, Logistics, Warehouse Fixed Mount Barcode Scanner - Cable Connectivity - Industrial Green

  • Part: 1727501
  • Model: FS40-WA20Z4-2C00W
£1,352.00

Availability

Out of Stock

  • General Information
    • Manufacturer
    • Zebra Technologies Corporation
    • Manufacturer Website Address
    • http://www.zebra.com/gb/en
    • Brand Name
    • Zebra
    • Product Type
    • Barcode Scanner

Comprehensive feature set, extraordinary flexibility, unsurpassed value

Today more than ever, the increasing demands of international commerce and its global supply chain are pressuring companies to deliver more - and to do it faster. From manufacturing to logistics to the end customer, success is driven by the ability to quickly move and track the products that drive your business.

Address it all with Zebra's FS40 Fixed Industrial Scanner, designed to meet the comprehensive requirements of today's production and delivery processes. The FS40 easily keeps pace with the fastest moving operations, enabling track-and-trace through the automatic and flawless decode of information on every part and package as it moves through production, storage and fulfillment - capturing even the most challenging barcodes. The result? Best-in-class production, warehousing, distribution and logistics processes that inspire businesses to reach their highest potential.

Zebra's FS40 Fixed Industrial Scanner sets the bar for simplicity, advanced data capture and return on investment. It all starts with Zebra Aurora™ - a powerful and intuitive software platform that makes it exceptionally easy to set up, deploy and run all Zebra Fixed Industrial Scanners, including the FS40. Once up and running, Zebra-exclusive features like ImagePerfect+ and PRZM Intelligent Imaging deliver first-time, every-time data capture. As your needs change, easily add support for new codes, increase scanning speed and upgrade to machine vision functionality - all through the simple purchase of software licenses that future-proof your investment. Take your success to the next level with extraordinary visibility into the processes that power your operations with the FS40 - only from Zebra.

Easy to set up

Automatic setup with Auto-Tune

Just Auto-Tune and run for consistent, reliable read rates - right out of the box. With the press of one button, Auto-Tune dials in the perfect image for faster and more accurate set up.

IoT ready with Zebra Savanna

The IoT-ready FS40 can send images to Zebra's subscription-based cloud service, Zebra Savanna - or any other cloud service - allowing you to meet industry regulations or store images for further analysis, all without the need to purchase and manage servers.

Power it all over Ethernet

Reduce setup complexity and cost with support for Power-over-Ethernet (PoE). This standard feature powers the FS40 and attached accessories right over the network, eliminating the cost of power drops and power supplies. Don't have a PoE infrastructure? No problem. You can also power the FS40 with a standard 24V DC power supply or even a standard USB-C port.

Limitless expansion options with USB-C

? Ready for a new level of flexibility? USB-C allows you to power your camera with a single cable and provides limitless accessory options. Seamlessly integrate with other Zebra devices such as a printer or tablet. You can also backup your system or save images for future analysis by connecting external storage devices to the FS40.

  • Warranty
    • Limited Warranty
    • 2 Year

  • Technical Information
    • Connectivity Technology
    • Cable
    • Scanning Capability
    • 1D
    • 2D
    • Barcode Symbology Supported
    • 1D:

      • Base 32 (Italian Pharma), Codabar/NW7, Code 11, Code 39, Code 93, Code 128, GS1 DataBar, I 2 of 5, Korean 3 of 5, MSI Plessey, UPC/EAN, DPM

      2D:

      • Aztec, Composite Codes, DataMatrix, Dotted DataMatrix, Dotcode, Han Xin, MaxiCode, PDF417, Micro PDF417, Postal Codes, QR Code, Micro QR, TLC-39, DPM

      OCR:

      • OCR-A, OCR-B, MICR, US Currency, Trainable OCR (available on select models or via an add-on OCR license)
    • Light Source
    • Laser
    • Image Sensor Type
    • CMOS
    • Scanner Range
    • Standard Range
    • Scanning Distance
    • 1.37 m
    • Features
    • Notification LED
    • Diagnostic Reporting
    • Beep
    • Field of View (Horizontal)
    • 46°
    • Field of View (Vertical)
    • 29°
    • Minimum Element Resolution (DataMatrix)
    • 0.13 mm
    • Maximum Element Resolution (DataMatrix)
    • 0.76 mm
    • Direct Part Marking (DPM) Decoding
    • Yes
    • Image Sensor Resolution
    • 1920 x 1200
    • Illumination Type
    • LED
    • Illumination Color
    • Red
  • Network & Communication
    • Infrared
    • Yes
  • Interfaces/Ports
    • Host Interface
    • Ethernet
    • Serial
    • USB
  • Power Description
    • Maximum Operating Power Consumption
    • 36 W
  • Environmental Conditions
    • Operating Temperature
    • 0°C to 45°C
    • Storage Temperature
    • -40°C to 70°C
    • Humidity (Non-condensing)
    • 5% to 90%
  • Physical Characteristics
    • Form Factor
    • Fixed Mount
    • Rugged
    • Yes
    • Color Family
    • Green
    • Product Color
    • Industrial Green
    • Product Material
    • Aluminium
    • Durability
    • Water Resistant
    • Dust Resistant
    • Shock Resistant
    • Vibration Resistant
    • Chemical Resistant
    • Oil Resistant
    • Height
    • 53.3 mm
    • Width
    • 63.5 mm
    • Depth
    • 91.4 mm
    • Weight (Approximate)
    • 399.7 g
  • Miscellaneous
    • Ingress Protection (IP) Rating
    • IP65
    • IP67
    • Application/Usage
    • Industrial
    • Logistics
    • Manufacturing
    • Warehouse
    • Distribution
    • Environmental Compliance
    • Restriction of Hazardous Substances (RoHS)
    • Waste Electrical and Electronic Equipment Directive (WEEE)
