BIG PERFORMANCE IN A SMALL PACKAGE
The DSM04XX Fixed Scan Module is the solution you need for high performance fixed position scanning in a compact form factor. Available in WVGA and Megapixel models with different Field of View and Depth of Field. The Wide-Angle model is particularly useful for embedded applications where space is at a premium.
RUGGED CONSTRUCTION
The enclosure is constructed with high impact resin that is resistant to cleanings solvents and disinfectant solutions. IP54 particulate and water sealing allows rugged and dependable scanning performance.
SIMPLE INTEGRATION
The DSM04XX Fixed Scan Module provides simple electrical and mechanical integration for system designers. Included mounting hardware allows mounting from all sides of the device at any angle. Interface options include USB, RS-232 or multi-interface models allowing 'plug-and-play' installation perfect for integrators who must support multiple platforms and applications.
- General Information
- Manufacturer
- Datalogic S.p.A
- Manufacturer Website Address
- http://www.datalogic.com
- Brand Name
- Datalogic
- Product Type
- Barcode Scanner
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Connectivity Technology
- Cable
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
1D:
All standard 1D codes including:
- UPC/EAN/JAN
- P2 / P5 add-ons
- Code 39
- Italian Pharmacode 39
- Code 128
- C128 ISBT
- I 2 of 5
- Standard 2 of 5
- Interleaved 2 of 5
- Industrial 2of 5
- Datalogic 2of5
- IATA; Code 11
- Codabar
- ABC Codabar
- EAN 128
- Code 93
- MSI/Plessey
- RSS-14
- BC412
- Databar Limited
- Databar Omnidirectional
- Databar Expanded
- IATA
- Trioptic
- Matrix 2/5
- Telepen
- Composite codes CC-A
- CC-B
- CC-C
2D:
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
Postal Codes:
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Korea Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
Stacked Codes:
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
- Light Source
- LED
- Image Sensor Type
- Imager
- Scan Mode
- Trigger/Sense
- Scanning Distance
- 599.44 mm
- Features
- Beep
- Notification LED
- Grayscale Image Capture
- Field of View (Horizontal)
- 52°
- Field of View (Vertical)
- 40°
- Reading Angle (Skew)
- 60°
- Reading Angle (Pitch)
- 60°
- Reading Angle (Roll)
- 180°
- Image Formats
- BMP
- JPEG
- Maximum Ambient Light
- 100000 lux
- Drop Specification
- Withstands repeated drops from 3 ft onto a concrete surface.
- Minimum Print Contrast
- 25%
- Minimum Element Resolution (Code 39)
- 0.08 mm
- Maximum Element Resolution (Code 39)
- 0.51 mm
- Minimum Element Resolution (DataMatrix)
- 0.25 mm
- Maximum Element Resolution (DataMatrix)
- 0.38 mm
- Image Sensor Resolution
- 1280 x 960
- Illumination Type
- LED
- Illumination Color
- White
- Interfaces/Ports
- Host Interface
- Ethernet
- Environmental Conditions
- Operating Temperature
- -20°C to 50°C
- Storage Temperature
- -40°C to 70°C
- Humidity (Non-condensing)
- 5% to 95%
- Physical Characteristics
- Form Factor
- Fixed Mount
- Rugged
- Yes
- Color Family
- Black
- Product Color
- Black
- Product Material
- Resin
- Durability
- Water Resistant
- Dust Resistant
- Weight (Approximate)
- 96 kg
- Miscellaneous
- Ingress Protection (IP) Rating
- IP54
- Application/Usage
- Retail
- Self-checkout
- Ticketing
- Manufacturing
- Healthcare
- Platform Supported
- Android
- Linux
- PC
- Environmental Compliance
- China Restriction of Hazardous Substances (China RoHS)
- Restriction of Hazardous Substances (RoHS)
