- General Information
- Manufacturer
- Honeywell International, Inc
- Manufacturer Website Address
- http://www.honeywell.com/sites/uk/
- Brand Name
- Honeywell
- Product Line
- Xenon Ultra
- Product Type
- Barcode Scanner
Today's retailers consistently face increasing demands for a seamless and memorable customer service. In order to achieve the efficiency needed to create elevated customer experiences, retailers need a scanning solution that empowers associates to move through their workflows precisely and without impedance.
The Xenon Ultra for retail is a premium evolution of the widely known legacy Xenon and Xenon XP general purpose scanners, taking our industry-leading scan performance and reliability one step further.
The Xenon Ultra 1960g incorporates Honeywell's next generation of scanning capability - allowing retailers to stay productive and keep customer service as their top priority. With optional dual-camera extended range (XR) models, retailers can use the scanner for both up-close and extended, bottom-of-the-basket scanning.
Available in a cordless Bluetooth configuration which offers premium accessory upgrades such as interchangeable power sources, contactless charging and magnetic retention capabilities.
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Connectivity Technology
- Cable
- Light Source
- LED
- Image Sensor Type
- Imager
- Scan Pattern
- Area
- Scanner Range
- Standard Range
- Scanning Distance
- 727.96 mm
- Features
- Beep
- Notification LED
- Field of View (Horizontal)
- 42°
- Field of View (Vertical)
- 36°
- Reading Angle (Skew)
- 65°
- Reading Angle (Pitch)
- 65°
- Reading Angle (Roll)
- 360°
- Motion Tolerance
- 4000 mm/s
- Maximum Ambient Light
- 100000 lux
- Drop Specification
- 1.8 m (6 ft) to concrete across operating temp range
- Minimum Print Contrast
- 15%
- Minimum Element Resolution (Code 39)
- 0.08 mm
- Maximum Element Resolution (Code 39)
- 0.51 mm
- Minimum Element Resolution (DataMatrix)
- 0.13 mm
- Maximum Element Resolution (DataMatrix)
- 0.25 mm
- Minimum Element Resolution (PDF417)
- 0.13 mm
- Maximum Element Resolution (PDF417)
- 0.17 mm
- Image Sensor Resolution
- 1280 x 1080
- Illumination Type
- LED
- Illumination Color
- White
- Air Electrostatic Discharge (+/-)
- 15kV
- Power Description
- Maximum Operating Power Consumption
- 2.50 W
- Environmental Conditions
- Operating Temperature
- 0°C to 50°C
- Storage Temperature
- -40°C to 70°C
- Humidity (Non-condensing)
- 0% to 95%
- Physical Characteristics
- Form Factor
- Handheld
- Color Family
- Black
- Product Color
- Black
- Weight (Approximate)
- 147.2 g
- Miscellaneous
- Ingress Protection (IP) Rating
- IP52
- Application/Usage
- Retail
- Assembly Line
- Component Tracking
- Manufacturing
- Light/Clean Manufacturing
- Inventory
- Self-checkout
- Commercial Service
